The CYSI Portable Handheld Grinder is a compact, lightweight grinding and polishing tool for on-site metallographic sample preparation, weld inspection, and surface finishing of metallic components. Variable speed control, interchangeable abrasive disc attachments (SiC paper, diamond pad, polishing cloth), and ergonomic grip design enable rapid material removal and surface preparation directly on large workpieces or in field inspection environments where bench-top equipment cannot be used.
Specifications
| Parameter | Value / Details |
|---|
| Product Model | CY-Grind-Portable |
| Type | Portable handheld grinder/polisher |
| Speed Range | 1,000–10,000 RPM (variable) |
| Motor Power | 180 W brushless motor |
| Disc Size | Ø 50 mm or Ø 75 mm |
| Attachment Types | SiC abrasive disc, diamond lap disc, polishing pad |
| Grit Range | P80–P4000 (SiC) / 9–0.5 µm (diamond) |
| Weight | ≈ 0.8 kg (excluding disc) |
| Handle | Ergonomic rubberised grip — anti-vibration |
| Power Supply | Corded — AC 220 V / 50 Hz |
| Cable Length | 2 m |
| Safety | Overload protection, dust guard |
| Supply Voltage | AC 220 V / 50 Hz |
| Total Power | 180 W |
| Applications | On-site metallographic prep, weld grinding, surface finishing |
Trade Information
| Trade Detail | Information |
|---|
| Minimum Order Quantity | 1 Unit |
| Supply Ability | 4 Units Per Month |
| Delivery Time | 3–8 Weeks |
| Main Domestic Market | China |
| Export Markets | Worldwide |
| Payment Terms | T/T, L/C, Western Union, PayPal |
| Packaging | Wooden crate with foam-padded export packing |
| Warranty | 12 Months from date of commissioning |
| After-Sales Service | Online technical support + on-site service available |
| Customization | Available on request |
