CYSI polypropylene cavity spin coater with superior chemical resistance to acids, bases, and organic solvents, vacuum chuck, programmable speed control, and integrated solvent vapour exhaust for photoresist and sol-gel coating.
The CYSI PP Cavity Spin Coater features a polypropylene (PP) chamber offering excellent resistance to corrosive acids, strong bases, and aggressive organic solvents — making it ideal for HF-based processes, sol-gel chemistries, and perovskite precursor solutions that would damage standard stainless steel or aluminium chambers. An integrated exhaust port safely removes solvent vapours, and the programmable vacuum chuck accommodates a wide range of substrate sizes.
| Parameter | Value / Details |
|---|---|
| Chamber Material | Polypropylene (PP) — chemically resistant |
| Chemical Resistance | Excellent — acids, bases, organic solvents |
| Speed Range | 0–8000 rpm (programmable) |
| Vacuum Chuck | Integrated vacuum substrate clamping |
| Exhaust | Integrated solvent vapour exhaust port |
| Applications | Photoresist, HF processes, sol-gel, perovskite precursors, acidic/alkaline solutions |
| Trade Detail | Information |
|---|---|
| Minimum Order Quantity | 1 Unit |
| Supply Ability | 4 Units Per Month |
| Delivery Time | 1–16 Weeks |
| Main Domestic Market | China |
| Export Markets | Worldwide |
| Payment Terms | T/T, L/C, Western Union, PayPal |
| Packaging | Wooden crate with foam-padded export packing |
| Warranty | 12 Months from date of commissioning |
| After-Sales Service | Online technical support + on-site service available |
| Customization | Available on request |
