The CYSI Powder Magnetron Sputtering Coating Machine deposits uniform metallic, oxide, and nitride nanofilms on powder and particle materials using a vibration-agitated sample stage combined with a DC magnetron source. Ideal for modifying battery active materials, catalysts, abrasives, and electrode powders, this system ensures all-surface coating uniformity that conventional sputtering systems cannot achieve on loose powder.
Specifications
| Parameter | Value / Details |
|---|
| Product Model | CY-MSP-Powder |
| Sputtering Method | DC magnetron sputtering |
| Sample Stage Type | Vibration-agitated powder tray |
| Tray Capacity | Up to 500 g per batch |
| Target Size | 2-inch (Ø 50.8 mm) or 3-inch (Ø 76.2 mm) |
| DC Power Supply | 500 W |
| Base Pressure | < 5 × 10⁻⁴ Pa |
| Working Pressure | 0.3–2 Pa (Ar atmosphere) |
| Vacuum System | Turbomolecular pump + rotary vane pump |
| Target Materials | Au, Ag, Al, Ti, Cr, Cu, Ni, alloys, oxides (RF option) |
| Film Thickness Control | Deposition time + power |
| Vibration Frequency | Adjustable — ensures all-surface exposure |
| Supply Voltage | AC 220 V / 50 Hz |
| Total Power | ≈ 2 kW |
| Overall Dimensions | 550 × 450 × 750 mm |
| Applications | Battery powders, catalysts, abrasives, SEM conductive coating |
Trade Information
| Trade Detail | Information |
|---|
| Minimum Order Quantity | 1 Unit |
| Supply Ability | 4 Units Per Month |
| Delivery Time | 3–8 Weeks |
| Main Domestic Market | China |
| Export Markets | Worldwide |
| Payment Terms | T/T, L/C, Western Union, PayPal |
| Packaging | Wooden crate with foam-padded export packing |
| Warranty | 12 Months from date of commissioning |
| After-Sales Service | Online technical support + on-site service available |
| Customization | Available on request |
