The CYSI Medium-Frequency Vacuum Induction Melting Furnace delivers rapid, efficient melting and refining of metals and alloys under vacuum or inert atmosphere using a medium-frequency (1–10 kHz) induction power source. The intensive electromagnetic stirring promotes homogeneous melt composition, degassing, and inclusion removal. Tilt-pour casting enables clean, controlled pouring into preheated moulds for precision alloy development and pilot-scale casting research.
Specifications
| Parameter | Value / Details |
|---|
| Product Model | CY-VIM-MF |
| Induction Frequency | 1–10 kHz medium frequency |
| Induction Power | 25–100 kW (selectable model) |
| Melting Capacity | 0.5–50 kg (model dependent) |
| Maximum Temperature | 1700 °C |
| Vacuum Level | < 1 × 10⁻² Pa |
| Backfill Gas | High-purity Ar — casting under protective atmosphere |
| Crucible Material | MgO, Al₂O₃, or graphite |
| Casting Method | Tilt-pour — motorised 0–100° |
| EM Stirring | Yes — inherent induction stirring |
| Vacuum System | Turbomolecular pump + rotary vane pump |
| Temperature Measurement | Optical pyrometer + thermocouple |
| Supply Voltage | AC 380 V / 50 Hz, 3-phase |
| Overall Dimensions | 1200 × 900 × 1800 mm |
| Applications | Steel, Ni, Ti, Co, Cu, precious metal alloy melting and casting |
Trade Information
| Trade Detail | Information |
|---|
| Minimum Order Quantity | 1 Unit |
| Supply Ability | 4 Units Per Month |
| Delivery Time | 3–8 Weeks |
| Main Domestic Market | China |
| Export Markets | Worldwide |
| Payment Terms | T/T, L/C, Western Union, PayPal |
| Packaging | Wooden crate with foam-padded export packing |
| Warranty | 12 Months from date of commissioning |
| After-Sales Service | Online technical support + on-site service available |
| Customization | Available on request |
